C-band
C-band BUC, 25–100 W
Outdoor block upconverter for satellite uplinks: L-band IF in, 5.725–6.525 GHz out, with full remote monitoring and control.
C
BUC0206 & BUC0214 series · Outdoor
Block Upconverters (BUC)
Outdoor block upconverters for satellite uplinks: C-band 25–100 W with SCPI, web and SNMP monitoring and control, and compact Ku-band 2–6 W.
Our BUC platforms
Ku-band
Ku-band BUC, 2–6 W
Compact outdoor block upconverter for Extended Ku-band uplinks — 1 kg, WR-75 output, 13–26 VDC.
Ku
Key features
Two power platforms in one family — C-band 25–100 W (BUC0206 series) and Ku-band 2–6 W (BUC0214 series)
Automatic lock to an external 10 MHz reference, with an internal reference option
C-band models: remote M&C over SCPI, web GUI, SNMP and RS-232/RS-485; Ku-band models: status monitoring and LED indicators
Input/output overdrive and temperature monitoring, with built-in self-test
Waveguide RF output, with flange hardware included in the scope of supply
Compact, outdoor-rated housings — C-band units include a pole-mount kit
Typical applications
Earth-station and teleport satellite uplinks
VSAT hub and remote-terminal uplinks
Broadcast and DTH contribution links
Need a different band or power?
We design BUCs to your frequency plan and power level: custom sub-bands, LO frequencies and interfaces.
Talk to our engineersC-band vs. Ku-band BUC
| Parameter | C-band BUC (BUC0206) | Ku-band BUC (BUC0214) |
|---|---|---|
| IF input | 975–1775 MHz | 950–1700 MHz |
| RF output | 5725–6525 MHz | 13.75–14.50 GHz |
| LO frequency | 4750 MHz | 12.80 GHz |
| Psat range, min. | 25–100 W | 2–6 W |
| Gain | ≥ 60 dB | ≥ 56 dB |
| DC supply | 48 VDC | +13 to +26 VDC |
| RF output interface | CPR-137G waveguide flange | WR-75 waveguide |
| Dimensions | 175 × 145 × 250 mm max. | 110 × 110 × 60 mm max. |
| Weight | — | 1 kg max. |
Specifications subject to change without notice.
